• Chrome front bumper w/Spectra Gray cover
• Chrome rear bumper w/step pad
• Dark argent air dam
• Body-side molding w/chrome trim
• Wheel opening flares
• Deluxe chrome grille
• Dual composite halogen headlamps w/auto on/off
• Daytime running lamps
• Fog lamps
• Cargo area lamp
• Dual chrome fold-a-way pwr heated mirrors
• Solar-Ray tinted glass (all windows)
• Deep tinted rear quarter/back glass
• Swing-out rear quarter windows
• Dual rear access doors hinged to rear of cab
• Intermittent windshield wiper system
• Removable tailgate w/badge name/decal
• Floor covering/under dash insulation

• LT decor
• Leather reclining heated bucket seats w/inboard armrest, dual pwr recline/ lumbar/thigh support/seatback bolster, 2-position 6-way memory driver seat
• 3-passenger folding rear bench seat w/matching trim
• Floor console
• Color-keyed full floor carpeting w/front/rear rubber floor mats
• Leather-wrapped steering wheel
• Tilt wheel
• Passlock theft deterrent security system
• Message center warnings-inc: system malfunction, trans overheat, low fuel, low coolant, vehicle security, oil level/temp/pressure/change needed
• Warning tones-inc: key-in-ignition, seat belt, headlamp, turn signal
• Cruise control
• Auto pwr door locks/windows w/backlit switches
• Keyless entry w/content theft alarm
• Illum entry
• Air conditioning
• Heater/defogger w/side window defoggers
• Elect rear window defogger
• ETR AM/FM stereo w/compact disc, cassette-inc: seek-scan, digital clock, auto tone control, cassette search/repeat, theft lock, speed compensated volume, enhanced performance speaker system
• Dual dash cup holders
• Dual covered pwr points
• Color-keyed soft vinyl door trim panels w/cloth inserts-inc: map pockets w/carpeted trim, door reflectors
• Electrochromic rearview mirror w/8-point compass & outside temp display
• Overhead console
• Color-keyed cloth headliner
• Dual color-keyed padded cloth sunshades w/driver storage clip, passenger mirror
• Passenger assist handles
• Lighting-inc: dome w/delayed entry feature, ashtray, glove box, underhood
• Dual foldaway coat hooks

• Four-wheel anti-lock brake system
• Driver & front passenger airbags w/passenger side deactivation switch
• Manual lap/shoulder safety belts, front/rear outboard seat positions
• Manual lap safety belts, center seat positions
• Head restraints at outboard seating positions
• Daytime running lamps
• Side door guard beams
• High/low note horn

HD TRAILERING SPECIAL EQUIPMENT

• weight-distributing hitch platform
• aux trans cooler

LOCKING DIFFERENTIAL

• premium carbon fiber friction plates

FIRM RIDE SUSPENSION PKG

• monotube 36mm shocks

• Preferred Equipment Group 1SC: Fourth Door
• HD Trailering Special Equipment
• Locking Differential
• HD Suspension
• Cruise control
• Heated driver and front passenger seats
• Leather front seat upholstery
• Driver seat power reclining
• lumbar support
• cushion tilt
• fore/aft control and height adjustable control
• Automatic full-time 4WD
• Vortec 6L V-8 regular gasoline
• engine with 300HP
• Vortec 6L V-8
• Mechanical
• Immobilizer
• 3 12V power outlets
• Front fog lights
• Leather steering wheel
• Heated driver and passenger side door mirrors
• Manual tilting steering wheel
• Metallic paint
• 16 x 6.5-inch front and rear polished aluminum wheels
• LT245/75SR16 AS BSW front and rear tires
• 2 airbags
• Driver front impact airbag
• Cancellable front passenger air bag
• Auto-locking doors
• 4-speed automatic
• Selectable mode transmission
• Leatherette rear seat upholstery
• Manual climate control
• Cabin air filter
• Rear under seat climate control ducts
• Exterior temperature display
• Transmission electronic control
• Automatic
• Reflector headlights
• Halogen headlights
• Auto on/off headlight control
• Daytime running lights
• Bucket front seats
• Driver seat with 8-way directional controls
• Front passenger seat armrest
• Front passenger seat with 8-way directional controls
• Driver seat with 2-way power lumbar
• Front passenger seat with 2-way power lumbar
• Sport steering wheel
• 4-wheel disc brakes
• 4-wheel antilock (ABS) brakes
• Rear bench seat
• Fold-up rear seat cushion
• Full folding rear seats
• Four-wheel drive
• Security system
• Firm ride suspension
• Seating capacity: 5

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 15.3
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4410
• Gross Axle Wt Rating - Rear (lbs): 6000
• Curb Weight - Front (lbs): 3235
• Curb Weight - Rear (lbs): 2140
• Gross Vehicle Weight Rating Cap (lbs): 8600
• Gross Combined Wt Rating (lbs): 14,000
• Gross Combined Wt Rating (lbs): 13,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 11,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 11,000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2500
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 6000
• Axle Type - Front: Hypoid
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4500
• Axle Capacity - Rear (lbs): 6000
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Front (mm): 32
• Shock Absorber Diameter - Rear (mm): 36
• Shock Absorber Diameter - Rear (mm): 32
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 13.0 x 1.14
• Tires
• Front Tire Order Code: QIZ
• Rear Tire Order Code: QIZ
• Spare Tire Order Code: QIZ
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Front Tire Capacity (lbs): 2205
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2205
• Revolutions/Mile @ 45 mph - Front: 680
• Revolutions/Mile @ 45 mph - Rear: 680
• Revolutions/Mile @ 45 mph - Spare: 680
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 15.0
• Steering Ratio (:1), At Lock: 13.0
• Turning Diameter - Curb to Curb (ft): 48.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 143.5
• Length, Overall w/o rear bumper (in): 227.6
• Width, Max w/o mirrors (in): 79.7
• Height, Overall (in): 74.4
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 47.0
• Front Bumper to Back of Cab (in): 138.7
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): 78.7
• Ground to Top of Load Floor (in): 34.1
• Frame Width, Rear (in): 42.1
• Ground Clearance, Front (in): 7.8
• Ground Clearance, Rear (in): 8.2
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 60.2
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 56.9
• Ext'd Cab Cargo Volume (ft³): 49.7
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 2500
• Body Style: Ext Cab 6.5' Fleetside
• Body Code: E63
